非标自动化设备初次投入使用时的检查调试细节有哪些?

浏览量

  标准的自动化设备满足不了需求差异化的生产需求,这时候就需要企业根据自己的实际生产需求及生产线的特点来定制非标自动化设备,在初次投入使用时需要进行检查和调试,红宝自动化就设备调试细节给大家做一下详细的介绍。
  Standard automation equipment can not meet the demand differentiation of production needs. At this time, enterprises need to customize non-standard automation equipment according to their actual production needs and the characteristics of the production line. When they are put into use for the first time, they need to be checked and debugged. Hongbao automation will give you a detailed introduction of the equipment debugging details.
  非标自动化设备运行前的电气检查调试:
  Electrical inspection and commissioning of non-standard automation equipment before operation:
  控制电路检查(主电路断开,接通控制电路空载试验)
  Control circuit check (no load test with main circuit disconnected and connected)
  1、检查各电路及元器件的动作顺序是否正确。
  Check whether the action sequence of each circuit and component is correct.
  2、检查连锁环节及联动装置、各保护环节等信号装置的动作是否正确。
  Check whether the actions of interlocking links, linkage devices, protection links and other signal devices are correct.
  3、检查行程开关、限位开关,并调整使其动作在准确位置。
  Check the travel switch and limit switch, and adjust it to make it move in the accurate position.
  4、检查各元器件触头接触的可靠性、动作的灵活性、应无卡住、粘住或停滞现象,且无过大的噪声及线圈过热现象。
  Check the contact reliability of each component contact and the flexibility of action. There should be no jamming, sticking or stagnation, and no excessive noise and coil overheating.
  主电路检查:按电气原理图要求的参数对非标自动化设备主电路进行调整。
  Main circuit inspection: adjust the main circuit of non-standard automation equipment according to the parameters required by the electrical schematic diagram.




  非标自动化设备一般检查:
  General inspection for non-standard automation equipment:
  1、对各元器件进行清扫,检查接触器、继电器等可动器件的动作是否灵活,接线头是否牢固、是否有漏接、错接。
  Clean the components, check whether the action of contactor, relay and other movable devices is flexible, whether the connector is firm, whether there is leakage or wrong connection.
  2、检查主电路接线,注意极性。
  Check the main circuit wiring and pay attention to the polarity.
  3、检查各种控制与保护电器,如时间继电器、热继电器等的整定值是否符合线路要求,熔断器的熔体是否合适等。
  Check whether the setting values of various control and protection electrical appliances, such as time relay and thermal relay, meet the line requirements, and whether the fuse melt is suitable.
  4、检查行程开关、限位开关等的、触头使用是否正确,转动是否灵活及内部有无异物。
  Check whether the contact of travel switch and limit switch is used correctly, whether the rotation is flexible and whether there are foreign matters inside.
  5、检查保护接地系统是否规范。接地线应牢固并保证接触良好。
  Check whether the protective grounding system is standard. The grounding wire shall be firm and in good contact.
  非标自动化设备绝缘检查:
  Insulation inspection of non-standard automation equipment:
  1、清洁灰尘、油污及碎物。
  Clean dust, oil and debris.
  2、检查导电部位对地绝缘,如电器的金属外壳、底座、支架或铁心等;两个不同电路间,如交流电路的各相之间、主电路与控制电路、保护显示电路之间及交直流电路间,各绝缘应不小于0.5兆欧。
  Check the insulation of conductive parts to the ground, such as the metal shell, base, bracket or iron core of electrical appliances; the insulation between two different circuits, such as the phases of the AC circuit, the main circuit and the control circuit, the protection display circuit and the AC / DC circuit, should not be less than 0.5 megohm.
  定制非标自动化设备的研发和生产在3C消费类电子、汽车、半导体行业、物联网等行业被广泛应用,并在行业内得到了良好的推广。山东红宝自动化有限公司更注重的是非标自动化设备的简洁设计,而且功能是自定义操作的,满足更多生产型企业的生产需求。
  The R & D and production of customized non-standard automation equipment is widely used in 3C consumer electronics, automobile, semiconductor industry, Internet of things and other industries, and has been well promoted in the industry. Shandong Hongbao Automation Co., Ltd. pays more attention to the simple design of non-standard automation equipment, and the function is user-defined operation to meet the production needs of more production-oriented enterprises.
