高速自动化包装流水线都包括哪些设备?有哪些核心优势?

浏览量
  包装在产品流通的过程中起到了保护产品,便于运输,促进销售的作用,早期的人工包装效率低,劳动强度大,如今自动化包装生产线设备的运用对企业来说,可实现产品的快速包装,效率高,而且劳动强度低。
  Packaging plays a role in protecting products, facilitating transportation and promoting sales in the process of product circulation. Early manual packaging has low efficiency and high labor intensity. Nowadays, the application of automatic packaging production line equipment can realize the rapid packaging of products, with high efficiency and low labor intensity.
  高速自动化包装流水线都包括哪些设备呢?与传统技术相比,具有哪些优势?
  What kind of equipment does high speed automatic packaging line include? What are the advantages compared with traditional technology?
自动化包装流水线方案
  1、升降缸和移动缸,实现可夹持组件的剩下升降和前后移动,可保证将第一传送带上的工件转运到第二传送带的纸箱内,夹持组件设置驱动缸、驱动杆和夹臂,通过驱动缸的出力轴伸缩可实现夹臂末端夹头的夹紧和松开。
  The lifting cylinder and the moving cylinder can realize the remaining lifting and forward and backward movement of the clamping components, which can ensure that the workpiece on the first conveyor belt is transferred to the carton of the second conveyor belt. The clamping component is provided with a driving cylinder, a driving rod and a clamping arm. The clamping and loosening of the clamping head at the end of the clamping arm can be realized through the expansion of the output shaft of the driving cylinder.
  其优点在于:实现了对工件的稳定夹持和放开,保证了工作的稳定转动,整个结构简单,制作方便,成本低,适用于小量和中批量产品的自动包装,劳动强度低,工作效率高。
  It has the advantages of stable clamping and releasing of the workpiece, ensuring the stable rotation of the work. The whole structure is simple, the production is convenient, and the cost is low. It is suitable for the automatic packaging of small and medium volume products, with low labor intensity and high work efficiency.
  2、夹持组件、升降块、升降缸、移动块、移动缸和支撑柱配套设置为两套,可在前进的过程中,第一个工位先完成一半工件的包装入箱,然后在第二个工位完成另一半包装入箱。
   There are two sets of clamping components, lifting block, lifting cylinder, moving block, moving cylinder and supporting column. In the process of moving forward, the first station completes the packaging of half of the workpiece into the box, and then completes the other half of the packaging into the box in the second station.
  其优点在于:在第二个工位工作的过程中,第一个工位同时工作,同时工作提升了工作效率;
  Its advantages are: in the process of working in the second station, the first station works at the same time, which improves the work efficiency;
  3、驱动缸、升降缸和移动缸均为气缸,驱动缸、升降缸和移动缸上均设有电磁阀,气缸成本低,而且型号多样。
  The driving cylinder, lifting cylinder and moving cylinder are all cylinders, and the driving cylinder, lifting cylinder and moving cylinder are equipped with solenoid valves, so the cost of the cylinder is low and the models are various.
  其优点在于:采用方便,满足多种行程的设定需求,设置电磁阀后气管连接更加方便,而且可以简化控制程序,更加方便操作;
  Its advantages are: easy to use, to meet the setting requirements of a variety of travel, the gas pipe connection is more convenient after setting the solenoid valve, and the control program can be simplified and the operation is more convenient;
自动化包装流水线方案
  4、调节柱的下端设有地脚螺钉,在安装的过程中,通过调节地脚螺钉,可保证第一传送带和第二传动带水平设置且二者高度一致。
  The lower end of the adjusting column is provided with an anchor screw. In the process of installation, by adjusting the anchor screw, the first and second transmission belts can be set horizontally and the height of the two belts is consistent.
  其优点在于:可保证传送过程中的稳定性,避免倾斜出现滑移问题,造成工件无法准确定位的问题。
  Its advantages are: it can ensure the stability in the process of transmission, and avoid the problem of sliding caused by tilt, resulting in the problem that the workpiece cannot be accurately positioned.
  就目前各大企业使用的自动化包装技术已然存在一定的问题,而高速自动化包装流水线设备是基于现有设备系统的升级与迭代,更符合现代化生产企业的包装需求,满足企业高要求的严格标砖,是包装行业不二的选择。
  At present, there are some problems in the automatic packaging technology used by major enterprises, and the high-speed automatic packaging assembly line equipment is based on the upgrading and iteration of the existing equipment system, which is more in line with the packaging needs of modern production enterprises and meets the strict standard bricks required by enterprises, which is the best choice for the packaging industry.
